DPK-DK-18
| Generating Set Model | |||
|---|---|---|---|
| Output Rating | PRIME | STANDBY | |
| 50 HZ 380-415V, 1500 RPM | 16.0 KVA | 17.5 KVA | |
| 12.8 KW | 14.0 KW | ||
| Engine | |||
| Engine Make | DEPCO | ||
| Engine Model | DEPCO-4L22 | ||
| Governing Type | Mechanical | ||
| Number of Cylinders | 4 | ||
| Cylinder Arrangement | In-line | ||
| Bore and Stroke (mm) | 85 x 95 | ||
| Displacement | 2.156 | ||
| Aspiration | Natural | ||
| Cycle | 4 Stroke | ||
| Compression Ratio | – | ||
| Cooling System | Water-Cooling | ||
| Frequency & Engine Speed | 50 HZ & 1500 RPM | ||
| PRIME | STANDBY | ||
| Gross Engine Power kWm | 17 kWm | – | |
| Fuel Consumption @ 100% L/hr | 3.58 | – | |
| Fuel Consumption @ 50% L/hr | – | – | |
| Alternator Data | |||
| Make | DEPCO | ||
| Model | DEPCO-13-3 | ||
| No. of Bearings | 1 | ||
| Insulation Class | H | ||
| Wires | |||
| Ingress Protection | IP23 | ||
| Excitation System | Shunt | ||
| Voltage | ±1% | ||
| Dimension & Weight | |||
| Length mm | 1400 | ||
| Width mm | 740 | ||
| Height mm | 850 | ||
| Weight*kg | 540 | ||
| Fuel Tank Capacity | 30 L | ||
| Control Panel | |||
| Make | DATAKOM | ||
| Model | D100 | ||
